  • HINAESS PowerShield

HINAESS PowerShield

Our advanced batteries are designed to provide the highest levels of performance, reliability, and efficiency, making them ideal for a wide range of applications.

Certificates

CE UN38.3 IEC62619

Available from warehouse

advantage

Product Features

01

DC Breaker built-in.

02

Parallel up to 32 modules.

03

Wide range inverter compatibility.

04

1C rate continuous charge/discharge

05

Ultra safe LFP material, 10 year warranty.

06

Handy monitor & flexible remote upgrade.

07

Second level protection, robust applications

08

Smart BMS management for longer lifespan.

09

Active balancing charging, low self consumption.

10

IP65 enclosure & Built-in heating system,
designed for outdoor use & extreme weather

Pictures

Detail Presentation

Why choose this product

Data

TECHNICAL DATA

Powershield

Model PowerShield
Cell Type LFP
Rated Power 5.12kWh
Rated Capacity 100Ah
Rated Voltage 51.2V
Charge Voltage 57.2V
Max Charge/Discharge Current 100A
Discharge Peak Current 105A / 15s, 150A / 0.5s
Parallel Up to 32 units parallelable w/o extra device needed, slave battery
drops oine or come back alive does not affect system running
IP Level IP65
Dimension 500*650*167mm
Weight 60kg
Communication CAN/RS485
Compatible Inverter Victron, Luxpower, Deye, Voltronic, SMA
Goodwe, Growatt, Sofar, Solark, SRNE, Must
Humidity 5%~85% RH (No condensation)
Work Temperature -20 ℃ ~ +55 ℃, heating system built-in
Storage Temperature -10 ℃ ~ +35 ℃
Remote Maintenance Handy monitor & flexible remote upgrade,
Original firmware backup to prevent upgrade failure
Protection
Warranty * 10 year, 6000 cycles
Certification CE UN38.3 IEC62619
Protection Over charge/discharge/current/voltage/temperature protection
Short circuit protection, Reverse connection protection
Charge balance, Low SOC protection
